Power switch black 20mm, 10A 250V (00815393)

Round power switch for 20mm diameter attachment. MAX 10A 250V. Orange light. Fits for many cooker hoods, lamps & other installations. 4,8mm Abiko -connections.

• single-acting, remaining positions 1 - 0.
• MAX 10A 250V.
• Orange light
• frame diameter 23 mm
• Mounting hole diameter 20 mm
• Depth of switch from collar to connector ends 23 mm
• Depth from the collar to the bottom of the switch body 14.5 mm
• 4.8mm Abiko connectors 3 pcs
• can also be used for low current installations 1-36V

Forssan Huoltopalvelu Ltd does not take any responsibility for accidents occurring in the installation of products or damage caused by incorrectly installed products. The installation of any electronic spare part has to be installed by a professional with electrical permits required by law. If an electronic component is installed by a person without electrician degree or permits the customer is responsible for any possible accidents / damage.
